PB-160A Tablet Or Capsule Bottling Packing Line, Capsule Counting Machine , Urban

Automatic Tablet/Capsule Bottle Packaging Lines are suitable for counting and filling wide range of tablet sizes between3~13mm and hard gelatin capsules #5~#00 in plastic bottles, with volume ranges 15 ~ 300ml.
Availability:
  • PB-160A

  • Urban

Introduction

Automatic Tablet/Capsule Bottle Packaging Lines are suitable for counting and filling wide range of tablet sizes between3~13mm and hard gelatin capsules #5~#00 in plastic bottles, with volume ranges 15 ~ 300ml. It is the most complete, counting and filling, paper and desiccant inserting, capping, inspecting, induction sealing to pressure sensitive labeling and reliable performance. Our counter comes with Japan Made PLC control with Color Touch Screen Panel. Vibrating Nozzles, Dust Collection System, secure bottle neck system for precision filling, No Bottle- No Fill, Tool-Less dismantle for cleaning and maintenance, automatic lifting system for quick bottle height changing, etc. are among standard features on each.


line

Specifications

line

Part 1
Fully-Automatic Bottle Unscrambler

Model PBL-160 QQ图片20190307111117
Max.capacity 120 Bottle/Min  ( Depend on bottle size )
Size of Container 20ML-500ML
Suitable container Round / square plastic containers
Voltage AC220V , Single Phase, 50/60Hz
Power 0.3 KW
Air Consumption/ Air Pressure 0.2 M3/h 0.4 Mpa
Overall Dimension 1006*1506*1200 mm
Weight 200kg


Part 2
Desiccant Sachet Filling Machine


Model PBGZ-160 pb-160a tablet or capsule bottling packing line - 副本11111945
capacity Max. 120  Bottles/Min ( Depend on bottle size )
Size of Container 20-500ML
Voltage 220V  AC , Single Phase, 50/60Hz
Power 0.3 KW
Overall Dimension 1600×750×1800 mm
Weight 280kg


Part 3
8-Tray Electromic Counting Machine(Double-Nozzle Type)

Model PBDS-8B QQ图片20190307110207
capacity 70-80 bottles/min ( 30 pcs/bottle )
50-60 bottles/min ( 50 pcs/bottle) 40 bottles/min ( 60 pcs /bottle )
Size of Capsule #00-#5 Capsule
Size of Tablet Max. Dia.22mm
Size of Bottle 15-500ML
Voltage AC220V , Single Phase, 50/60Hz
Power 1000W
Air Consumption 0.8 M3/h
Air Pressure 0.5Mpa
Overall Dimension 2000 (L ) *1500( W ) * 1600 ( H)mm
Weight 300kg (with conveyor)


6-Tray Electromic Tablet or Capsule Counting Machine

Model PBDS-6 6通道USD11000-16000
capacity 40 bottles/min ( 30 pcs/bottle )
40 bottles/min ( 50 pcs/bottle)
30-40 bottles/min ( 60 pcs /bottle )
Size of Capsule #00-#5 Capsule
Size of Tablet Max. Dia.22mm
Size of Bottle 15-500ML
Voltage AC220V , Single Phase, 50/60Hz
Power 1000W
Air Consumption 0.8 M3/h
Hopper Volume 30ltrs
Overall Dimension 1600 (L ) *1500( W ) * 1600 ( H)mm
Weight 250kg (with conveyor)


Part 4
High-Speed Press Capping Machine

Model PBX-160 II PB-160A TABLET OR CAPSULE BOTTLING PACKING LINE5185
capacity Max. 100 Bottles/Min  ( Depends on the bottle mouth Dia.)
Size of Cap Dia. 20-65 MM
Size of Bottle 15-500 ML
Air supply 0.2 M3/h
Air Pressure 0.4Mpa
Power 220V , Single Phase, 50/60Hz 2000W
Overall Dimension 2600 (L)*1100(W)*2000(H)mm
Weight 500kg (with conveyor)



Part 5
Self-adhesive Labeling Machine

Model PBTB-160 QQ图片20190307110210
capacity Max. 150 Bottles/min
Size of Container Diameter :30-110mm Height :30-200mm ( Round Bottle )
Voltage AC220V 50/60HZ Single-phase
Power 1100 W
Air Supply 0.2 M3/h
Air Pressure 0.4 Mpa
Overall Dimension (L) 2000 × (W) 1150 × (H) 1650mm
Weight 250KG


Our Service

  • Through years of experience, Urban provides several services which cover almost all requirements of clients. These services include production, design, inspection, packaging, shipment, product recommendation, after-sales service,  and multiple client solutions.


  • We can supply mаsk raw materials for you if you can't buy materials from in your local market.


  • We have a good relationship with more than four international shipping companies who have rich experiences in handling different kinds of shipping ways and also the customs declarations and clearances. They all have good shipping services to save you time and costs.


  • We have a professional international technical team. To provide you with after-sales service and guidance.

After-sale Service

We will always be responsible for the machine you purchased. Nearly 10 professional after-sales personnel provide global technical services. In this way, we also provide professional services, such as guide installation services, equipment commissioning and operation services, maintenance services and equipment parts replacement. Ensure the quality of your products, while eliminating your worries.

  1. 1. The whole machine is guaranteed for 1 years.

  2. 2. Provide professional machine operation and maintenance guidelines.

  3. 4. Provide 24-hour online professional technical services .




About Us

Urban was founded in 2003, is a professional engaged in the research, development, sale and service of mask production machine, melt-blown cloth production machine, protective clothing production machine, liquid capsule filling machine and other medical production equipment and pharmaceutical machinery.


Company has won a member of the Chinese pharmaceutical equipment industry small and mid sized enterprise of Zhejiang province, wenzhou science and technology innovation oriented enterprises, through the 1509001 quality management system certification, eu CE mark certification, product has self-supported import and export right, the company existing authorized more than 20 patents, among them 2 product invention patents, also has many sets of high-end machining center equipment and testing equipment, provide quality assurance for the quality of products.


capsusal (8)             capsusal (7)

Certification

Certificate medical             Certificate medical             Certificate medical

Workshop

  • Name of Base: URBAN

  • Time of establishment: 2003

  • Base address: No.371 The First Development Road, Economy Development Zone, Ruian City, Zhejiang Province, China

  • Floor area: 3000 m2

  • Number of employees: 120

  • Products: NJP full automatic capsule filling machine, NJYF hard capsule liquid filling machine,sealing machine connecting line,semi-automatic capsule filling machine,capsule polishing machine, etc.

  • Certification obtained: ISO CE FDA

  • Capacity: 5500 capsules/min

medical workshop

mask workshop             mask workshop             mask workshop


With first-class product quality and perfect after- sales service, our products are sold well in provincesand cities, autonomous regions, Taiwan, Hong Kong and other areas, and exported to North America, SouthAmerica, Europe, Australia, Africa, southeast Asia, the Middle East and more than 60 countries around theworld.
