High Accuracy and Reliable Fully Automatic Powder Capsule Filler Auto Granules Pellets Empty Capsule Filling Making Machine NJP-4000D
NJP-4000D can be used to encapsulate powder, granules and pellets in pre- determined dosages. The machine can be divided into upper and lower components. The lower components are mechanical and electrical components that drives the capsule filling process which consists of parts like motor, vacuum pump, drive belts, safety clutch, air compressor etc.The filling of the capsules is carried out in the upper segment of the machine consisting of components like capsule hopper, powder hopper, 12 stations on a rotary plate, filling station assembly and other components as part of filling process.
Product details
NJP-4000D capsule filling machine automatic is the third generation of innovative products. It has 8 invention patents. Capsule maker machine filling can fill powder, granules and other materials into hollow capsules (000#, 00#, 0#, 1#, 2#, 3#, 4#, 5#). Auto capsule filling machine can automatically finish the production process including sowing, capsule separating, filling, locking, unqualified capsule rejected and finished products output. It has the advantages of accurate loading, stable operation and no dust. It meets the GMP requirements, it is an ideal equipment for filling Chinese, Western medicines and health care product .
Product parameters:
| Production capacity | 240,000 pcs/h |
| Applicable product | Power,granule,pellet,tablet |
| The number of holes | 29 |
| The probability of capsule use | above 99.8% |
| powder | 380/220V 50hz（customized) |
| Total Powder |
12kw |
Product description
Featurers
1. Capsule fill pharmaceutical maintenance is very easy, just need lubricate the cam one timein the capsule filling machine then the grease can be continuously lubricated, ensuring smooth transmission of the transmission mechanism. and no oil leaking,conform to the GMP requirements.
2. Rotary design to obtain a patent for utility model, the sealing ring using imported SIL silicone rubber, effectively prevent powder into the internal turntable, good sealing performance, no dust overflow pollution; Transverse biaxial adapt PTFE oil-less bearing, no need refueling; modular structure, equipped with jog operation, convenient maintenance and cleaning, replacement of mold only 15 minutes.
3. NJP-4000D size 4 capsule filler machine adopts large high precision cam indexing box, completely changed the past 83DS failure frequency, even the phenomenon of the fracture of the force shaft and the output shaft. It is the only enterprise that adopts 100DS and 100DS indexing box in our country at present. The continuous operation of the equipment has been guaranteed.
4. The inner groove cam of NJP-4000D fill capsule automatic is formed by CNC machining center once, no splitting, no splicing, no gap, better stability, no noise in the transmission mechanism in high-speed production of equipment.
Faqs
2. Disassemble and clean the filing station to clear the excess material to prevent blockage and rust, after the production is finished.
3. Add lubricating oil to the vacuum pump regularly and clean up the dust.
4. Fill enouah water over half of the barrel body in water tank reqularly.
