Capsule Filling Machine Types Urban Machinery Brand
Product details of the capsule filling machine types
Product Description
The raw materials of Urban Machinery capsule filling machine types undergoes the strict selection, which is conducted by our workers. Customers can trust the quality and safety of this product. Wenzhou Urban Machinery Co., Ltd. is managed by a team of professionals.
Product Features
1.The split-type design of the capsule loading mechanism and the patented fully-enclosed structure prevent the capsules from improperly falling into the capsule transmission room and ensure the capsules to perform smoothly
2. The patented powder filling mechanism includes several patented techniques like the irregular multi-surface powder keeper, the lateral angled feeder, etc., which makes the powder evenly distribute within the powder storage room, correctly and smoothly flow into the capsules, and achieves an extremely precise capsule filling process.
3.The patented modular punch as well as the bi-nodal feed hopper is of simple dismounting and with accurate positioning.
4.The patented capsule ejection system effectively protects the filled capsules from breaking by the machine.
5.The patented integrated rotary table with ultra-precision has features like small size, light load, long service life, three years free of oil and maintenance and so on
6.The whole set of the molds and all the parts that need daily cleaning and maintenance are equipped with locating pins, and the connection as well as fastening among different parts is extremely simple. As the fastening tool is standardized in size, a small spanner can easily dismount all the parts.
7.The host is intelligent remote controlled. By using the remote control to jog and test-run the machine after cleaning and maintaining the molds or equipment, the operation becomes easy and safe.
8.All the connectors of the air pipes apply standardized clamps, which are much easier to dismantle and clean than others.
Product parameters:
|
Capsule size |
#000 |
#00 |
#0 |
#1 |
#2 |
#3 |
#4 |
#5 |
|
Locked Length |
26.14mm |
23.30mm |
21.7mm |
19.4mm |
18.0mm |
15.9mm |
14.3mm |
11.1mm |
|
Capsule Volume |
1.37ml |
0.91ml |
0.68ml |
0.5ml |
0.37ml |
0.3ml |
0.21ml |
0.13ml |
(The filling amount may vary because of the powder difference)
|
Model |
NJP-3000D |
|
Output |
177600pcs/h |
|
Applicable capsules |
No. 00-5 / Powder or granule/fixed number of pellets/Safety capsule A-E |
|
Power Supply |
The main engine is 3kw with 9kw |
|
Net weight |
2500kg |
|
Packing size |
1300*1650*2200mm |
Product description
Faqs
Company Feature
• Urban Machinery's products are sold well in China and are exported to North America, Eastern Europe, and Southeast Asia.
• Urban Machinery has established a complete professional service system to provide quality services based on customer demand.
• Urban Machinery's location has unique geographical advantages, complete supporting facilities, and traffic convenience.
• After years of development, Urban Machinery has a firm foothold in the industry and gradually becomes the industry leader.
Hello, if you are interested in Urban Machinery's products or services, feel free to call and consult us. We are dedicated to serving you.
